Material Specifications
Structure, Fronts and Upper Panels: made from 2 cm thing wood particle panels covered in melamine with a matte, glossy or metallic lacquered effect with painted wood veneer. By glossy front we mean the external side and its edges, while the interior is supplied with the corresponding matte lacquered colour
Back Panels: made of medium density wood particle panels, 0,8 cm thick, with synthetic finishing.
Drawer: 1,4 cm thick with 0,8 cm thick bottom panel in wood particle panels, interior in Jute textured finish. The external transparent glass shelf has a thickness of 1,2 cm.
Perimeter Body: made of medium density wood particles with a thickness of 1 cm covered in melamine in a matte, metallic lacquered, or painted wood veneer finish.
Feet:
- in ABS, height cm 1,5
- methcrylate / shaped th. cm 1,5
- cylindrical th. Ø cm 2
N.B: the bases with cylidrical or shaped metal feet or methacrylate feet, feature an extra central support foot.
Technical Specifications and Equipment
Drawer Opening: the fronts with a visible upper edge have a minimal handle, normally positioned in the centre of the front flush with the outside; for all the others there is push-pull opening.
Drawer Guides:
- opening with Minimal handle: ghigh-sliding metal guides with total extraction, end stop block and dynamic load capacity of 30 kg. "Blumotion" soft return mechanism integrated into the guide for a smooth and silent closing. Anti-release pin and vertical adjustment of the inclination of the fronts integrated in all the guides of the system. Stabilizing bar added for drawers with a width of 90 cm and "Movento" guides with built-in stabilizer, as well as lateral adjustment of the fronts for drawers with a width of 120 and 150 cm.
- push-pull opening: high-sliding metal guides with total extraction, limit switch block and dynamic load capacity of 30 kg. Sliding synchronizer integrated in the guides of drawers with a width greater than 45 cm. Anti-release pin and vertical adjustment of the inclination of the fronts integrated in all the guides of the system.
Drawer width is cm 120 and 150 with"Movento" guides and lateral adjustment on the fronts.
Combination Table for the Minimal Handle with the Structure
| Structure |
Handles
|
| Clay Oak |
matte Terranova |
| Havana Oak |
matte Brown |
| Charcoal Oak |
matte Brown |
| Cuba Oak |
matte Brown |
| Grey Oak |
matte Brown |
| Natural Knotted Oak | matte Brown |
| Caramel Knotted Oak |
matte Brown |
| Heat-treated Oak |
matte Brown |
| Canaletto Walnut |
matte Brown |
| matte lacquer |
matte lacquer |
| glossy lacquer |
glossy lacquer |
| metallic lacquer |
metallic lacquer |
| Eco walnut melamine |
matte Brown |
| Medium Elm melamine |
matte Lead |
| Dark Elm Melamine |
matte Brown |
| Nature Loto melamine |
matte Rope Grey |
| Dove Grey Loto melamine |
matte Rope Grey |
| Earth Loto melamine |
matte Terranova |
| Sand Sketch melamine |
matte Canvas |
| Rock Sketch melamine |
matte Silica |
| Tobacco Sketch melamine |
matte Beaver |
Optional
Lighting: 3000K LED bar under base: external profile in satin aluminum 1,2 x 1,2 cm with opal plastic casing, with development from 14.4 to 28.8W, depending on the size of the base, with power supply included. Switched on via connection to the home network or via optional remote control.
To know more...
Heat-treated Oak: this particular oak wood finish is characterised by the contrats created between light veins and a dark, full backround. This effect is created by the high temperature to which the veneer is subjected, determining a different colour between the harder and softer parts of the wood, with a pleasant and random chiaroscuro.
Laminate: it is a wood-effect coating usually applied to different materials, such as melamine panels. This covering consists of layers obtained by pressing together various sheets of paper soaked in melamine or phenolic resins. There are different types and aesthetically it can have different aspects, such as the features of real wood.
Cleaning and Maintenance
The surfaces must not be placed in contact with water, liquids in general, excessive heat and humidity.
Cleaning should be carried out exclusively with a damp cloth and neutral detergents, drying immediately with a soft cloth; The use of alkaline, solvent and abrasive products is not recommended. The products are not suitable for external use.
